SJ-FTTH-MN-4-2 FTTH Fiber Outlet, 2×SC + 4×LC

SJ-FTTH-MN-4-2 Specifications

Key Features

• Hybrid SC + LC on one plate — two SC ports and four LC ports side by side, so legacy and high-density patching meet at one outlet.
• One termination, two standards — the incoming cable terminates once; both connector types are served from the same splice area.
• Compact hybrid footprint — 95 × 87 × 21 mm, smaller than running two separate plates.
• Project-friendly — suits upgrades where existing SC infrastructure stays while new LC services are added.
• ABS+PC housing — rigid, white, home and office friendly finish.
• Rated −40 °C to +70 °C — covers corridors and plant rooms as well as living spaces.

Where the SJ-FTTH-MN-4-2 Fits

• Mixed SC/LC sites — offices and MDU units where both connector standards are in service.
• Upgrade projects — keep the existing SC drop live and add LC services at the same point.
• Apartment entry points — where the {DROP} terminates and both router (SC) and structured cabling (LC) are patched.

Need a uniform 4-port socket instead? See the MN-4B (86 type) or the SK-1 (2 × SC or 4 × LC). Full range: Fiber Wall Socket category.

Installation Notes

• Fix the outlet to the wall with screws; clamp the incoming cable before terminating.
• Terminate SC and LC pigtails or field connectors separately, and label both rows — hybrid plates are easy to mis-patch without labels.
• Keep bends above the minimum radius for both fiber runs inside the plate.
• For general wall-outlet mounting, see how to install a fiber wall socket in your house.

Hybrid and 4-Port Outlets in the Range

Full range: Fiber Wall Socket category
